Everything in this series, assembled. YOLO is a convolutional backbone, a grid, anchor boxes, IoU and non-max suppression, arranged so that detection is one forward pass [1].
The name is the claim: you only look once. Prior detectors ran a classifier at many locations and scales, or generated region proposals and classified each [2][3]. YOLO makes detection a single regression from image to tensor.
The sliding-window half of that history is worth one note, because it is the same insight arriving early: OverFeat showed that running a classifier at every window is equivalent to one convolutional pass over the whole image, since the fully connected layers can be rewritten as convolutions [4]. Shared computation across overlapping windows is what makes a dense grid of predictions affordable at all.
The pipeline
flowchart TB
I["input image<br/>416 x 416 x 3"] --> B["convolutional backbone<br/>(the architectures from parts 10-18)"]
B --> G["output tensor<br/>13 x 13 x (k x (5 + n_classes))"]
G --> T["threshold on p_c<br/>discard low-confidence boxes"]
T --> N["non-max suppression<br/>per class"]
N --> O["final detections"]
Note where the network stops. Everything after the output tensor — thresholding and NMS — is post-processing, outside the model and outside the loss.
The output tensor
The image is divided into an \(S \times S\) grid. Each cell predicts \(k\) boxes, each carrying a confidence, four coordinates and the class scores:
\[S \times S \times \big(k \times (5 + n_{\text{classes}})\big)\]For a 13×13 grid, 5 anchors and 80 COCO classes: \(13 \times 13 \times 425 = 71{,}825\) numbers, describing 845 candidate boxes.
Crucially the grid is not a separate mechanism — it is the feature map. A 416×416 image through a backbone with five stride-2 stages comes out at 13×13, and each of those 169 positions is one grid cell. The “grid” is the spatial dimension of the final convolutional layer, which is why the whole thing is one pass.
Parameterising the box
The obvious approach — have the network output \(b_x, b_y, b_h, b_w\) directly — trains badly. Early in training the predictions are arbitrary, boxes land anywhere in the image, and the model takes a long time to stabilise.
YOLOv2 constrains the prediction to the cell instead [5]. The network outputs \(t_x, t_y, t_w, t_h\), and:
\[b_x = \sigma(t_x) + c_x, \qquad b_y = \sigma(t_y) + c_y\] \[b_w = p_w e^{t_w}, \qquad b_h = p_h e^{t_h}\]where \((c_x, c_y)\) is the cell’s top-left corner and \((p_w, p_h)\) is the anchor’s shape.
Two design decisions worth reading carefully:
- The sigmoid on the centre forces \(\sigma(t) \in (0,1)\), so a cell’s predicted midpoint cannot leave that cell. The assignment rule from part 24 said the cell containing the midpoint owns the object; this makes that property hold by construction rather than by hope.
- The exponential on the size guarantees a positive width and height, and makes the network predict a multiplier on its anchor rather than an absolute size. Predicting “1.1× the usual car” is a far easier regression than predicting 87 pixels, and it is why good anchor shapes matter.
This one change was worth about 5 mAP over direct prediction.
Confidence
\(p_c\) is not simply “is there an object”. It is trained toward
\[p_c = \Pr(\text{object}) \times \text{IoU}(\text{predicted}, \text{truth})\]so the confidence reflects localisation quality as well as presence. A box that finds the right object but frames it badly should not be confident, and this is what makes the confidence a sensible thing to rank by in NMS.
The final score used for each class is
\[\text{score} = p_c \times \Pr(\text{class}_i \mid \text{object})\]which is what gets thresholded and fed to non-max suppression.
Why one pass matters
| Detector | mAP (VOC 2007) | FPS |
|---|---|---|
| R-CNN [2] | 66.0 | 0.05 |
| Faster R-CNN (VGG-16) [3] | 73.2 | 7 |
| YOLO [1] | 63.4 | 45 |
| YOLOv2 (416) [5] | 76.8 | 67 |
The original YOLO traded accuracy for a 6× speed-up over Faster R-CNN. YOLOv2 gave the accuracy back — anchor boxes, the box parameterisation above, batch normalisation [6] and higher-resolution training — while getting faster still.
At 0.05 FPS, R-CNN takes 20 seconds per image. At 67 FPS, YOLOv2 runs faster than video. That is not a better number on the same axis; it is the difference between a research result and something you can point at a camera.
What actually matters
One pass is why it is fast, and also why it struggles with small objects. Every object competes for a slot on a coarse grid. At 13×13, a flock of birds or a crowd at distance maps many objects onto few cells, and anchors only partly help because those objects also have similar shapes. This is a structural consequence of the design, addressed later by predicting at several scales at once rather than by any change to the loss.
Most of what makes YOLO work is not in the YOLO paper. The backbone is the architecture line from parts 10 to 18; batch normalisation, anchor shapes from k-means, and multi-scale training arrived in v2; the training recipe matters as much as any of it. Reading the v1 paper alone tells you about the framing, not about what makes a modern one-stage detector accurate.
NMS being outside the network is the design’s clearest weak point. The loss optimises the raw tensor; the output you consume has been through a non-differentiable, sequential, threshold-dependent filter that the model never sees. Every mistake NMS makes in a crowd is a mistake the model was never given a chance to learn around. That gap is exactly what set-prediction detectors were built to close.
Source code
tf2_object_detection.ipynb— runs pre-trained detectors end to end, where the output tensor, the score threshold and the NMS step are all visible as separate stages.
References
- [1]J. Redmon, S. Divvala, R. Girshick, and A. Farhadi, “You only look once: Unified, real-time object detection,” in IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2016, pp. 779–788.
- [2]R. Girshick, J. Donahue, T. Darrell, and J. Malik, “Rich feature hierarchies for accurate object detection and semantic segmentation,” in IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2014, pp. 580–587.
- [3]S. Ren, K. He, R. Girshick, and J. Sun, “Faster R-CNN: Towards real-time object detection with region proposal networks,” in Advances in Neural Information Processing Systems (NeurIPS), 2015.
- [4]P. Sermanet, D. Eigen, X. Zhang, M. Mathieu, R. Fergus, and Y. LeCun, “OverFeat: Integrated recognition, localization and detection using convolutional networks,” in International Conference on Learning Representations (ICLR), 2014.
- [5]J. Redmon and A. Farhadi, “YOLO9000: Better, faster, stronger,” in IEEE Conference on Computer Vision and Pattern Recognition (CVPR), 2017, pp. 7263–7271.
- [6]S. Ioffe and C. Szegedy, “Batch normalization: Accelerating deep network training by reducing internal covariate shift,” in International Conference on Machine Learning (ICML), 2015, pp. 448–456.
